Reverse Proxy Benchmark 2025: NPM vs. NPM+ (HTTP/3) vs. Zoraxy

Why Use a Reverse Proxy? The Basics Explained

In the world of home servers and self-hosting, we often juggle numerous applications, each accessible on a different port. Remembering addresses like 192.168.1.10:8080, 192.168.1.10:9000, and 192.168.1.10:3000 is cumbersome and insecure.

This is where a Reverse Proxy comes in. It acts as a central gatekeeper for all incoming requests. Instead of memorizing dozens of ports, we can simply access a subdomain like service.your-domain.com. The reverse proxy receives the request, handles SSL/TLS encryption (the https in the address bar), and forwards it internally to the correct service and port.

In a previous video, I compared several reverse proxies. Today, we’re taking it a step further by putting three modern, visually-oriented contenders through a performance benchmark:

1. Nginx Proxy Manager (NPM): The popular classic, serving as our stable baseline.
2. NPM+: A community fork of NPM, where we will specifically enable HTTP/3.
3. Zoraxy: A new but extremely powerful and modern challenger.

We’ll install all three using Docker and put their performance to the test with the tools wrk and k6.

Glossary: Key Terms and Technologies

The Preparation: Our Test Setup

For a fair comparison, we need a consistent test environment.

1. Installing Server Tools

I am renting four servers from Hetzner. On three of them, I install Docker:

# Add Docker's official GPG key:
sudo apt-get update
sudo apt-get install ca-certificates curl
sudo install -m 0755 -d /etc/apt/keyrings
sudo curl -fsSL https://download.docker.com/linux/ubuntu/gpg -o /etc/apt/keyrings/docker.asc
sudo chmod a+r /etc/apt/keyrings/docker.asc

# Add the repository to Apt sources:
echo \
  "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.asc] https://download.docker.com/linux/ubuntu \
  $(. /etc/os-release && echo "${UBUNTU_CODENAME:-$VERSION_CODENAME}") stable" | \
  sudo tee /etc/apt/sources.list.d/docker.list > /dev/null
sudo apt-get update
sudo apt-get install -y docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin

On the fourth server, I install wrk and k6:

sudo apt install wrk -y
sudo gpg -k
sudo gpg --no-default-keyring --keyring /usr/share/keyrings/k6-archive-keyring.gpg --keyserver hkp://keyserver.ubuntu.com:80 --recv-keys C5AD17C747E3415A3642D57D77C6C491D6AC1D69
echo "deb [signed-by=/usr/share/keyrings/k6-archive-keyring.gpg] https://dl.k6.io/deb stable main" | sudo tee /etc/apt/sources.list.d/k6.list
sudo apt-get update
sudo apt-get install k6

Alternatively, this can be done using a Cloud-Init-Config.

2. A Common Network for All Containers

To allow our proxies to communicate with the backend service, we create a common Docker network on each of the three servers.

sudo docker network create proxy

3. The Backend Service: Homepage

As the target service for our proxies, we use the gethomepage/homepage dashboard. It’s lightweight and perfect for our test.

homepage/docker-compose.yml:

services:
  homepage:
    image: ghcr.io/gethomepage/homepage:latest
    container_name: homepage
    environment:
      - HOMEPAGE_ALLOWED_HOSTS=your.domain.com # ADJUST HERE
      - PUID=1000
      - PGID=1000
    volumes:
      - ./config:/app/config
    networks:
      - proxy
    restart: unless-stopped
    deploy:
      resources:
        limits:
          cpus: '1.0'
          memory: 1G

networks:
  proxy:
    external: true

We start this container with sudo docker compose up -d. It has no public port – access is exclusively through our reverse proxies.

The Contenders in Detail

1. Nginx Proxy Manager (NPM)

The classic. Known for its extremely simple, web-based configuration.

npm/docker-compose.yml:

services:
  app:
    image: 'jc21/nginx-proxy-manager:2.12.6'
    container_name: npm
    restart: unless-stopped
    ports:
      - '80:80'
      - '443:443'
      - '81:81'
    volumes:
      - ./data:/data
      - ./letsencrypt:/etc/letsencrypt
    networks:
      - proxy
    deploy:
      resources:
        limits:
          cpus: '1.0'
          memory: 1G

networks:
  proxy:
    external: true

We create the data and letsencrypt folders. After starting with docker compose up -d, we log in at http://<SERVER_IP>:81 and create a proxy host pointing to the homepage service on port 3000. The SSL certificate is automatically obtained via Let’s Encrypt.

2. NPM+ (with HTTP/3)

The modernized version of NPM. The key feature here is enabling HTTP/3.

npm-plus/docker-compose.yml:

services:
  app:
    image: 'ghcr.io/zoeyvid/npmplus:latest'
    container_name: npm-plus
    restart: unless-stopped
    ports:
      - '80:80/tcp'
      - '443:443/tcp'
      - '443:443/udp'
      - '81:81/tcp'
    environment:
      - 'PUID=1000'
      - 'PGID=1000'
      - 'TZ=Europe/Berlin'
      # To enable HTTP/3, you have to enable it in the settings page of the UI
    volumes:
      - ./data:/data
    networks:
      - proxy
    deploy:
      resources:
        limits:
          cpus: '1.0'
          memory: 1G

networks:
  proxy:
    external: true

The crucial difference is exposing port 443 for UDP. The configuration in the UI is identical to NPM, with an additional toggle in the settings to enable HTTP/3. The login password can be found in the logs: sudo docker compose logs.

3. Zoraxy

A modern challenger written in Go, focusing on performance and a clean UI. HTTP/3 is active by default.

zoraxy/docker-compose.yml:

services:
  zoraxy:
    image: tobiaskoch/zoraxy
    container_name: zoraxy
    restart: unless-stopped
    ports:
      - "80:80"
      - "443:443"
      - "443:443/udp" # HTTP/3 is on by default
      - "8000:8000"
    volumes:
      - ./config/:/opt/zoraxy/config/
      - ./plugin/:/opt/zoraxy/plugin/
      - /etc/localtime:/etc/localtime:ro
    networks:
      - proxy
    deploy:
      resources:
        limits:
          cpus: '1.0'
          memory: 1G

networks:
  proxy:
    external: true

Here, we create the config and plugin folders. After starting, we can access the admin UI at http://<SERVER_IP>:8000. Setting up a proxy host is just a few clicks away.

The Benchmark: The Results

I conducted two tests from the fourth server:

1. wrk: A raw stress test with 100 concurrent connections for 1 minute to measure maximum throughput (version 4.1.0).
2. k6: A dynamic scenario that slowly ramps up the load, holds it, and simulates load spikes to test realistic behavior (version 1.1.0).

wrk Results: Raw Power

wrk -t4 -c100 -d60s --latency your.domain.com

The wrk results are clear: Zoraxy is in a league of its own in terms of speed. It handles 50% more requests than Nginx Proxy Manager at a fraction of the latency. BUT: under this extreme, continuous fire, Zoraxy started to drop requests (701 timeouts). NPM and NPM+ remained perfectly stable.

k6 Results: Realistic Scenario

// The k6 script used for testing
import http from 'k6/http';
import { check, sleep } from 'k6';

export const options = {
  stages: [
    { duration: '30s', target: 50 },    // Phase 1: Ramp-up
    { duration: '1m', target: 50 },     // Phase 2: Soak
    { duration: '30s', target: 200 },   // Phase 3: Stress
    { duration: '1m', target: 200 },    // Phase 4: Soak
    { duration: '30s', target: 0 },      // Phase 5: Ramp-down
  ],
  thresholds: {
    'http_req_duration': ['p(95)<800'],
    'http_req_failed': ['rate<0.01'],
    'checks': ['rate>0.99'],
  },
};
// ... rest of the script ...

The dynamic k6 test paints a different picture. Here, all three contenders are perfectly stable and deliver error-free results. Zoraxy is again the fastest, closely followed by the classic NPM. NPM+ shows a slight performance overhead, likely due to the enabled HTTP/3 processing for the test tool’s HTTP/1.1 requests.

Final Verdict and Recommendation

So, which reverse proxy should you choose? It depends on your priorities.

• For Beginners and Stability Fans: Nginx Proxy Manager
  It’s the rock-solid choice. Incredibly easy to use and absolutely reliable in every scenario. The perfect, worry-free option.

• For the Modern All-Rounder: NPM+
  The ideal evolution. You get a familiar UI and modern features like HTTP/3 that can be enabled with a single click. The best compromise between stability, features, and ease of use.

• For Performance Hunters: Zoraxy
  The k6 test proved that Zoraxy is also perfectly stable in realistic scenarios. Its potential is undeniable, making it a contender you should definitely keep an eye on.
